rated load 1200kg
overall weight 2530kg
rated bucket capacity 0.35m/0.45 m3
engine power 24kw
...
Читать далее
engine type Quanchai QC2105
starting mode electric start-up
RPM 2200r/min
axle base 2050mm
rning radius 4300mm
imbing gradient 25°
discharge height 2700mm
discharge distance 860mm
movable arm lifting time 5 s
hydraulic cycle time 9 s
overall dimensions(L*W*H) 4650mm*1560mm*2400mm
Tire 8.25-16
tire pressure 0.3Mpa-0.4Mpa
driving form four wheel drive
transmission system mechanical transmission
